Damier Keypad | 82 x 144

Meljac’s most minimal keypad solution. The Damier collection offers low-profile push buttons with paired-back plate details that perfectly complement contemporary environments.

Brushed Brass (Champagne)

Hidden Screws | Straight Edge
MNA Catalog #DS-H-821443-8BP(SF)-S

Sandblasted Nickel (Microbillé Nickel)

Hidden Screws | Straight Edge
MNA Catalog #DR-H-821443-3BP(RF)-S

Damier Keypad | 82 x 144

Meljac’s most minimal keypad solution. The Damier collection offers low-profile push buttons with paired-back plate details that perfectly complement contemporary environments.

Product details

Plate dimensions

3.2″ x 5.7″ x .11″ | 82 x 144 x 3 mm

Switch options

1-8 push buttons

Push buttons can be configured according to specification, with respect to spatial limitations.

Available switch-type:

Momentary push button (BP) – normally-open – one contact closure

Push Button Shape – square or round
Push Button Profile – raised (default) or flush

Low-voltage dry contact push buttons for use in class-2 wiring circuits only and are not to be used with standard 120V electrical wiring.

Back box information

B00838 | plastic | new construction*
MELUS14482- NC16 | plastic | new construction*
MELUS14482 | metal | old construction

Metal boxes are stocked and available for immediate shipping.

*Printed-to-order in 10-15 business days.

View additional back box information

Certifications

UL/CSA Listed.

Finish + Custom options

Plate finish

Available to order in all metallic finishes and RAL powdercoats.

View Finishes

Switch finish

For the Damier collection, button finishes are matched to the plate finish by default.

If desired, button finish can be specified with an alternative finish to the plate finish.



Screw type

Hidden (default) or visible

Edge type

Straight (default) or beveled

Engravings

Numerous engraving fonts, sizes and styles available.  See Engraving Options page for more details.





Availability + Purchasing

PURCHASING

Available to order directly from Meljac North America.

To help ensure a successful project outcome keypads must be purchased through the entity responsible for system integration.

AVAILABILITY / LEAD-TIMES

Meljac products are made-to-order at our workshops in France.

Lead-times may vary depending on your selected plate options and current order volumes.

Please see the Current Lead Times section of our FAQs page for the most up-to-date information.
